제품 상세 정보:
|
| Key word: | Four-leg Grade 80 Alloy Steel Chain Sling, industrial Heavy Lift Chain Sling, for overhead lifting, chain sling assembly | Material: | High strength alloy steel |
|---|---|---|---|
| Strength of the chain: | Grade 80 | Chain accessory: | With Master Link Assemblies, Grab Hooks and Chain Shorteners |
| Finish: | Chain hot dip galvanized and accessories painted red or customized | Standard: | ISO1835, ISO3077, EN818-2 |
| Length: | Customized | Application: | Overhead lifting application, industrial lifting, heavy lift |
| Packaging: | Carton + pallet, wooden box, or custom | OEM or ODM services: | Yes, upon request |
| 단일 레그(톤) | 2-레그(톤) | 3-레그(톤) | 4-레그(톤) | 엔드리스 |
미터당 추가 중량 (kg/m) |
||||
| 0° | 0-45° | ＞45-60° | 0-45° | ＞45-60° | 0-45° | ＞45-60° | 0° | ||
|
직경 (mm) |
하중 계수 = 1 | 하중 계수 = 1.4 | 하중 계수 = 1 | 하중 계수 = 2.1 | 하중 계수 = 1.5 | 하중 계수 = 2.1 | 하중 계수 = 1.5 | 하중 계수 = 1.6 | |
| φ 6mm | 1.12 | 1.57 | 1.12 | 2.35 | 1.68 | 2.35 | 1.68 | 1.79 | 0.80 |
| φ 8mm | 2.00 | 2.80 | 2.00 | 4.20 | 3.00 | 4.20 | 3.00 | 3.20 | 1.40 |
| φ 10mm | 3.15 | 4.41 | 3.15 | 6.62 | 4.73 | 6.62 | 4.73 | 5.04 | 2.20 |
| φ 13mm | 5.30 | 7.42 | 5.30 | 11.13 | 7.95 | 11.13 | 7.95 | 8.48 | 3.80 |
| φ 16mm | 8.00 | 11.20 | 8.00 | 16.80 | 12.00 | 16.80 | 12.00 | 12.80 | 5.70 |
| φ 18mm | 10.00 | 14.00 | 10.00 | 21.00 | 15.00 | 21.00 | 15.00 | 16.00 | 7.30 |
| φ 20mm | 12.50 | 17.50 | 12.50 | 26.25 | 18.75 | 26.25 | 18.75 | 20.00 | 9.00 |
| φ 22mm | 15.00 | 21.00 | 15.00 | 31.50 | 22.50 | 31.50 | 22.50 | 24.00 | 10.90 |
| φ 26mm | 21.20 | 29.68 | 21.20 | 44.52 | 31.80 | 44.52 | 31.80 | 33.92 | 15.20 |
| φ 32mm | 31.50 | 44.10 | 31.50 | 66.15 | 47.25 | 66.15 | 47.25 | 50.40 | 23.00 |
